Features & Advantages
- Constant 240 tests/hour, one of the fastest small size biochemistry systems 100 µL minimum reaction volume
- Low water consumption ( 2.0-3.0 L/H )
- Close system and open system is optional
- High efficient washing station for cuvettes
- Random access, continuous loading
- Incorporated with liquid level sensor, volume tracking, collision detection and clot detection
- 24 hours refrigeration system with separate switch
- Unlimited STAT position
- 16 wavelengths range from 340 nm-800 nm
- Automatic cuvette wash & cell blank check
- Real-time reagent levels monitoring, displaying and alerting function
Specifications
| Equipment Type | Automatic discrete, unlimited STAT priority |
| Throughput | 240 tests/hour |
| ISE | Optional (200 tests/hour) |
| Measuring Principle | 1-Point Endpoint, 2-Point Endpoint, 2-Point Rate, Rate A, ISE technology |
| Calibration Options | 1-Point Linear, 2-Point Linear, Multi-Point Linear, Non-Linear, K Factor |
| Sample Type | Serum; Plasma; Urine; CSF |
| Sample Volume | Biochemistry: 2.0 μL-35.0 μL; ISE: 90.0 μL |
| Sample Handling | Up to 90 sample positions, continuous loading, 24 hours refrigeration function with separate switch |
| Reagent Handling | Up to 90 reagent positions, continuous loading, 24 hours refrigeration function with separate switch |
| Reagent Volume | 20 μL-350 μL |
| Reaction Temperature | 37.0 °C ± 0.2 °C |
| Reagent Bottle Volume | 10 mL + 30 mL, 50 mL |
| Reaction Time | 12 min / 32 min |
| Dispensing System | Sample & reagent probe with liquid level detection and clot detection |
| Wavelength | 16 wavelengths: 340 nm, 380 nm, 405 nm, 450 nm, 480 nm, 505 nm, 546 nm, 570 nm, 600 nm, 630 nm, 660 nm, 700 nm, 720 nm, 750 nm, 780 nm, 800 nm |
| Mixing System | 1 independent stirring needle (coated with TEFLON) |
| Dilution | Auto-dilution |
| Power Supply | a.c. 100 Vac - 240 Vac, 50/60 Hz |
| Barcode Type | code 128, code 39, code 93, codabar, 2/5 Interleaved |
| Reaction Volume | 100 μL - 380 μL |
| Cuvette | 80 optical plastic cuvettes, reusable, optical diameter is 5 mm |
| Light Source | 20 W / 12 V, halogen lamp, 2000 H |
| Absorbance Range | 0 ABS - 3.5 ABS |
| Water Consumption | Maximum 3.0 L/H (2.0 L/H; Single Reagent) |
| Weight | 68 Kg |
| Dimension | L x W x H = 730 mm x 500 mm x 620 mm (28.74 in x 19.69 in x 24.41 in) |
